Description
Features
- Universal AC input range selectable by a switch
- Protections: short circuit, overvoltage and overload
- Cooling by free air convection
- LED indicator for power on
- 100% full load burn-in test
- Low cost and high reliability
Specification
| Model | ATO-S-150-5 | |
| Output |
DC Voltage | 5V |
| Rated Current | 30A | |
| Current Range | 0 ~ 30A | |
| Rated Power | 150W | |
| Ripple & Noise (Max.)(Note 2) | 150mVp-p | |
| Voltage Adjust Range | 4.5 ~ 5.5V | |
| Voltage Tolerance (Note 3) | ±2.0% | |
| Line Regulation | ±0.5% | |
| Load Regulation | ±0.5% | |
| Setup, Rise, Holdup Time | 100ms, 50ms, 20ms at full load | |
| Input | Voltage Range | 88 ~ 132VAC/176V~264VAC (selected by a switch) or 248 ~ 370VDC |
| Frequency Range | 47~63Hz | |
| Efficiency (Typ.) | 78% | |
| AC Current (Typ.) | 3.2A/115V AC 1.6A/230V AC | |
| Inrush Current (Typ.) | Cold start: 35A | |
| Leakage Current | <3.5mA/240V AC | |
| Protection | Overload | 105~150% rated output power Protection type: Shut down output voltage, re-power on to recover. |
| Overvoltage | 5.75V ~ 6.75V Protection type: Shut down output voltage, re-power on to recover. |
|
| Environment | Working Temperature | -10 ~ +60℃ |
| Working Humidity | 20~90% RH non-condensing | |
| Storage Temperature | -20~+85℃ | |
| Storage Humidity | 10~95% RH non-condensing | |
| Temperature Coefficient | ±0.03%/℃ (0~50℃) | |
| Vibration | 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes | |
| Safety & EMC (Note 4) | Safety Standards | UL1012 UL60950-1, TUV EN60950-1, CCC GB4943 Approved |
| Withstand Voltage | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | |
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/70% RH | |
| EMC Emission | Compliance to EN55022 (CISPR22) Class B, EN61000-3-2, -3 | |
| EMC Immunity | Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, light industry level, criteria A | |
| Others | MTBF | ≥286.7K hrs MIN. MIL-HDBK-217F (25℃) |
| Dimension | 199*110*50mm (L*W*H) | |
| Weight | 0.8kg | |
| Note | 1. All parameters NOT specially mentioned are measured at 230V AC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″ twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance includes set up tolerance, line regulation and load regulation. 4. The switching power supply is considered a component which will be installed into final equipment. Please make sure that the final equipment still meets EMC directives. |
Dimensions (Unit: mm)
Details
SMPS Power Supply Applications
- Power Tools
Electric Saw, Drilling Machine, Ginder, Sand Blast Machine, Puching Machine, Weeding Machine, Air Compressor, etc. - Offices Devices
Computer, Printer, LCD Monitor, Scanning Machine, etc. - Electrics & Household Appliance
TV, VCRS, Radio, Dust Collector, Fan Lamp or LED Strip, Sewing Machine, Microwave Oven, Fridge/Freezr, Coffemarker, etc. - Industrial Equipemnt
Monitoring Equipment, Shipping, Vehicle, Metalhalide Lamp, Solar System, Wind Power Generation, etc.
7 tips for using a switching power supply
- Confirm whether specifications of input or output voltage comply with nominal value of the power supply before use.
- Check whether input and output leads are correctly connected before powering on for prevention of equipment damages.
- Check whether various components are tightened up. Check whether there are contacts between screws and electrical parts of power panel. Measure insulation resistance between shell and input or output leads for prevention of electric shock.
- Make sure the ground terminal is properly connected to the ground to grantee safety and reduce noise waves.
- Multiplexed output refers to a power supply with primary and secondary output. The primary output performs better than secondary output. In general conditions, the one with larger current is the primary output. To ensure adjustment rate and dynamic indicators of output load, it is required to at least carry 10% of its load. If using secondary output instead of the primary one, users should exert dummy load on the primary output. Please refer to the specifications of different models for more details.
- To be noticed that frequent switching of power supply will have negative influence on its life span.
- Operating environment and on-load level will influence life span of switching power supply.
