Description
Buy 200KV outrunner brushless DC motor at good price. High power 8kW, high torque 18 N.m, max input voltage DC 60 volts (powered by 14S batteries). Select a matching ESC controller to drive your electric skateboard better. Usually, ATO recommends buying a kit of 8000W BLDC motor.
Specification
| Model | ATO-BLDC-83100 |
| Max Power | 8000W (10 hp) |
| Rotation Speed KV (RPM/V) | 200KV |
| Max Current | 158A |
| No-load Current | 6.2A |
| Max Input Voltage* | DC 60V |
| Max Torque | 18 N.m |
| Resistance | 0.0133Ohm |
| Rotation Speed | 12000~15000 |
| Motor Length | 100mm |
| Motor Diameter | 83mm |
| Weight | 2 kg |
| SHAFT diameter | 12mm |
*Note: The motor is powered by 14S batteries, S is the number of batteries, voltage of every battery is 3.7V DC.
Water Cooled Brushless DC Motor Dimensions Drawing (Unit: mm)
ESC (Electronic Speed Controller) Selection for Water Cooled BLDC Motor
- The speed of BLDC motor does not exceed the speed of ESC, it can be matched and used.
- Brushless DC motor speed calculation formula: battery voltage * motor KV value.
Brushless DC motor stator speed calculation formula: motor KV value * battery voltage * motor pole pairs. - The limit speed of V4 series ESC is 60000 ERPM.
The limit speed of V6 series ESC is 15000 OERPM. - If the maximum speed of BLDC motor exceeds the speed of electric speed controller, the ESC can also be matched by reducing the working voltage of motor. But we do not recommend this, because it does not really play the role of brushless DC motor.
ESC (Electronic Speed Controller) Specification
| Model | Current Value | Number of Batteries (Input Voltage) |
| FSESC 4.12 | Continuous 50A, peak 240A | 3S-12S (8V-60V) |
| FSESC 4.20 | Continuous 50A, peak 240A | 3S-12S (8V-60V) |
| VESC 6.6 mini dual drive | 1-channel 100A continuous, 2-channel 200A continuous 1-channel peak 400A, 2-channel total peak 800A |
3S-12S (8V-60V) |
| VESC6.6 integrated switch dual drive version | 1-channel 100A continuous, 2-channel 200A continuous 1-channel peak 400A, 2-channel total peak 800A |
3S-12S (8V-60V) |
| FSESC6.6 VESC6.6 single drive integration | Continuous 60A, peak 150A | 3S-12S (8V-60V) |
| VESC4 dual drive integration | 50A continuous 1-channel, peak 100A 2-channel, peak 300A 2-channel | 3S-12S (8V-60V) |
| ODESC3.6 single drive/dual drive | 50A continuous 1-channel, peak 120A 1-channel | 3S-12S (8V-60V) |
| VESC6 dual drive | 1-channel 100A continuous, 2-channel 200A continuous 1-channel peak 400A, 2-channel total peak 800A |
3S-12S (8V-60V) |
| Single drive V6 75200 | Continuous 200A | 3S-12S (8V-60V) |
| Single drive VESC6 waterproof version | Continuous 60A, peak 150A | 3S-12S (8V-60V) |
Note: If you need to learn more details about ESC controllers, please contact us.
