ASCO 8316G064DC48/DCD – Solenoid Valve

Description

Specifications

• Valve Actuation: Solenoid
• Function: 3 way – 3/2 Normally Closed
• Body Material: Brass
• Flow (Cv): 3.2 Cv
• Pipe/Port Type and Size: NPT 1/2
• Min Ambient Temperature: 32°
• Max Ambient Temperature: 104°
• Min Fluid Temperature: 32°
• Max Fluid Temperature: 120°
• Product Weight: 3.9 lbs
• Watt Rating: 10.6 W
• Orifice Size: 5/8 in
• Coil Class: FT
• Coil Number: 238310-017-D
• Lead Length: 18 inch, ANY
• Mounting Brackets: OPTIONAL
• Carton Note: 1/2 X 5/8 3NC BRASS 10.6/F DC
• Kit Number: 314493
