Description
Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 35 Cv
- Pipe/Port Type and Size: NPT 1-1/2
- Min Ambient Temperature: 0°
- Max Ambient Temperature: 185°
- Min Fluid Temperature: 0°
- Max Fluid Temperature: 185°
- Product Weight: 0 lbs
- Voltage and Frequency: 24 AC with 60 Hz
- Watt Rating: 17.1 W
- Holding Current (VA): 40
- Orifice Size: 1-1/2 in
- Coil Class: FB
- Coil Number: 238610-105-D
- Lead Length: Any, 18 inch
- Carton Note: 1-1/2 X 1-1/2 2NC 17.1/F AC
- Kit Number: 300144
