Description
Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 20 Cv
- Pipe/Port Type and Size: NPT 1
- Media: Air, Inert Gas
- Min Operating Pressure (Air): 5 psi
- Max Operating Pressure (Air): 125 psi
- Min Ambient Temperature: 0°
- Max Ambient Temperature: 150°
- Min Fluid Temperature: 0°
- Max Fluid Temperature: 150°
- Product Weight: 3.9 lbs
- Voltage and Frequency: 220, 240 Volts AC with 50/60 Hz
- Watt Rating: 6.1 W
- Holding Current (VA): 16
- Orifice Size: 1-1/8 in
- Coil Class: FT
- Coil Number: 238210-058-D
- Lead Length: Any, 18 inch
- Carton Note: 1 X 1-1/8 2NC 6.1/F AC
- Kit Number: 316563
