Description
1 hp (0.75 kW) Air Compressor Features
- 2 gallon tank capacity
- 108L/Min air displacement
- Powerful 1 horsepower motor produces 3.8 CFM at 115 PSI for increased productivity
- Portable with small size, low cost, oil save, and energy save.
1 hp (750W) Air Compressor Description
| Model | ZB-00368B |
| Size | 50 (L)*19 (W)*51 (H) CM |
| Type of the Air Compressor | Direct drive |
| Tank Capacity | 2 Gal. (Can be customized) |
| Motor Power | 1 hp, 0.75 kW (Can be customized) |
| Power Source | AC Power |
| Voltage | 120V, 60Hz (Can be customized) |
| Air Delivery | 108L/Min, 3.8 CFM |
| Maximum Pressure | 8 Bar, 115 PSI |
| maximum Speed | 2880 rpm |
| Certification | CE, ROHS, CCC, ISO |
| Noise Level | with 80DB |
| Warranty | 1 Year |
| Cooling Method | Air Cooling |
| Weight | 22 kg |
Note: Tell us your application needs, we can customize the air compressor to meet your precise power, tank capacity, air delivery and rated voltage requirements.
Air Compressor Applications
Packing & Delivery
Details
Tips: What is a piston-type small air compressor?
The piston small compressor is the compressor which changes its internal volume by a group or several groups of cylinder or the piston with reciprocating motion. It consists of the compressor main engine, cooling system, regulating system, lubricating system, relief valve, electric motor and control equipment. The compressor and the motor are fastened to the machine base with bolts, and the base is fixed on the foundation by the foundation bolt.
