2″ Resilient Wedge Gate Valve

Description

Note: This gate valve cannot be used for drinking water.

Low price manual resilient wedge gate valve for sale, it has a nominal flow diameter of 2 inches and a nominal pressure of 1.6 MPa. ATO dual flex wedge gate valves provide reliable and effective flow control for a wide range of applications in oil, gas, chemical, power, metallurgical, marine and other industries.

Specification

• Model: ATO-WGV-50
• Nominal Diameter: 2″ (DN50)
• Nominal Pressure: 1.6 MPa
• Control Mode: Manual control
• Manual Operation: Switching handle (turbine)
• Connection: Flange
• Operating Range: 0-90°
• Material of Valve Body: Cast iron
• Material of Valve Plate: Cast iron
• Seat Seal: PTFE
• Media: Water, liquid, gas, oil, powder, steam, etc.
• Weight: 29kg

Features

• 2″ wedge gate valve features a gate with a wedge shape that allows for a tight seal when the valve is closed.
• DN 50 wedge gate valve has a full bore design, which means that the inside diameter of the valve is the same as the pipe it is connected to. This helps to minimize pressure drop and turbulence.
• The flexible gate valve is designed to allow for bi-directional flow, which means that fluid can flow through the valve in either direction.
• Wedge gate valves are capable of withstanding high pressures, making them ideal for use in applications where high pressures are present.
• When the valve is fully closed, the wedge gate provides a tight seal that prevents fluid from leaking through the valve.

Dimension (Unit: mm)
