Description
High pressure 2200W regenerative blowers for sale, which flows 210m³ air per hour and makes only 64 dB noise. It is suitable for mechanical drying, moisture and oil removal in industrial production.
Specification
| Model | ATO-2PB510H36 |
| Phase | 3 |
| Frequency | 50 |
| Power | 3 hp (2.2 kW) |
| Voltage (AC) | △220-240V / Y345-415V |
| Current | 9.7△ A / 5.6Y A |
| Max airflow | 210 m³/ h (124 cfm) |
| Rated vacuum pressure | -220 mbar |
| Rated compress pressure | 270 mbar |
| Noise | 64 dB (A) |
| Weight | 29 kg |
Dimention (Unit: mm)
| A | B | C | D | E | F | G | H | J | K | L | M | N | O | ΦP | Q | ΦR | S | U | V(1~) | V'(1~) | V1 (3~) | V1′ (3~) | YXZ | X-HOLES | ΦX | W |
| 334 | 337 | 120 | 260 | 295 | 346 | 191 | 175 | 128 | 115 | 155 | 96 | 87 | 48 | 55 | 83 | 14 | 4 | M8X17 | / | / | M25X1.5 | M16X1.5 | M8X20 | 0°/ 120°/ 240° | 200 | 29 |
Details
Tips: High pressure blower troubleshooting
- The motor fuse circuit is in poor contact or mechanically damaged, causing a certain phase of the fuse to blow.
- The three-phase fuse standard of the motor power supply circuit is different, and the fuse with a small capacity is blown. It should be replaced with the same standard fuse according to the power of the motor.
- The switch (isolating switch, rubber cover switch, etc.) in the motor power supply circuit and the contact of the contactor are in poor contact (burned or loose). Repair and adjust the moving and static contacts to make good contact.
- One phase of the line is missing phase. Detect the disconnection and connect it firmly.
